Refractory castable for metal mixer

Refractory castable for metal mixer


Classification:

The metal mixer is a thermal equipment for storing and homogenizing molten iron in the steel making plant. The lining material is subjected to the action of molten iron scouring, slag erosion, temperature change and large dynamic load vibration for a long time, and is easily damaged.
Send Mail

Product Details


The metal mixer is a thermal equipment for storing and homogenizing molten iron in the steel making plant. The lining material is subjected to the action of molten iron scouring, slag erosion, temperature change and large dynamic load vibration for a long time, and is easily damaged.



Features:
1. According to the use conditions of each part of the mixed iron furnace, the material types of the castable can be flexibly selected.
2. The thickness of the lining can be determined according to the use conditions of each part, which is scientific and effective.
3. Good insulation effect, energy saving and consumption reduction.
4. The construction efficiency is high and the labor intensity of the workers is low.



Item Index
HJ-60 HJ-65 HJ-70 HJ-60S Al2O3—Spinel—C
Al2O3 (%) ≥ 60 65 70 60 60
MgO (%) ≥         4
SiC (%) ≥       10 6
Bulk density(g/cm3) ≥  110℃×24h 2.4 2.6 2.7 2.6
Bending strength  (MPa) ≥ 110℃×24h 4 5 5 4
3h after burning 6(1350℃) 8(1400℃) 8(1400℃) 6(1400℃)
Cold crushing strength (MPa) ≥ 110℃×24h 30 30 30 25 35
3h after burning 50(1350℃) 50(1400℃) 60(1400℃) 50(1400℃) 40(1450℃)
Linear change rate  (%) ±0.5(1350℃) ±0.5(1400℃) ±0.5(1400℃) ±0.5(1400℃)
Application Furnace roof Wall/ Bottom Slag line, iron mouth Permanent layer
